Ideal operating conditions for magnetic drive pumps
The magnetic drive pump produced by Seken Pump has the characteristics of sealing, non-leakage, and corrosion resistance. It is widely used in petroleum, chemical, pharmaceutical, electroplating, environmental protection, water treatment, film and television printing and other fields. It is used to pump flammable, explosive, Toxic and precious liquid, it is an ideal pump for creating a leak-free, zero-pollution workshop.
The working conditions of the magnetic drive pump are:
Magnetic drive pump is a liquid that does not contain ferromagnetism and fibers with a density of not more than 1300kg/m3 and a viscosity of not more than 30×10-6m3/S. The rated temperature of the conventional magnetic drive pump is metal material or F46 lining, the high working temperature is 80℃, and the rated pressure is 1.6MPa; the operating temperature of the high temperature magnetic pump is ≤350℃; for the pump body is non-metal material, the high temperature is not Above 60℃, the rated pressure is 0.6MPa. For liquids with a density greater than 1600kg/m3, the magnetic coupling needs to be designed separately.
