Waste oil gear pump - KCB 1200

  • item no.:

    KCB1200KCB-1200
  • lead time:

    Customer Date
  • product orgin:

    china saiken pumps
  • shipping port:

    Tianjin China
  • payment:

    L/C Or T/T
  • color:

    Customer Color
  • description
KCB 1200 Waste oil gear pump Specifications:


     Model        Capacity
        (L/min)
    Pressure
        (Bar)
    Speed
     (rpm)
     Caliber
      (inch)
    Power
     (kw)
        Efficiency
   KCB 1200          1200         6     740         6 ”       37           45%
Packing details
                 715*350*876 Export standard wooden case


Application:
KCB gear pumps applies to transfer non-corrosive lubricating-oil or equivalent liquid without solid particle and fibre at temperature below 300℃ and with the viscosity of 5×10-6~1.5×10-3m2/S(5-1500cSt), such as diesel oil, crude oil, engine oil, cargo oil,hydraulic oil etc. If it is coupled with copper gear and ex-proof motor, it is suitable for gasoline, benzene transfer. It also fit for drink, milk, honey, vegetable oil transfer if coupled with stainless steel material.

Feature:
This pump is coupled with pressure relief valve. There are cast iron, cast steel and 304/316/316L stainless steel pump body for option. The seal can be oil seal, packing seal or mechanical seal at customer’s demand.

KCB gear pump model parameter:


Model Caliber
(Inch)
Flow
(L/min )
Pressure
(MPa )
Suction Lift
(m )
kcb gear pump
with Motor power
(KW )
KCB-18.3 3/4 18.3 1.45 5 1.5
KCB-33.3 3/4 33.3 1.45 5 2.2
KCB-55 1″ 55 0.33 5 1.5
KCB-83.3 1 1/2″ 83.3 0.33 5 2.2
KCB-135 2″ 135 0.33 5 4
KCB-200 2″ 200 0.33 5 4
KCB-300 3″ 300 0.33 5 5.5
KCB483.3 3″ 483.3 0.33 5 7.5
KCB483.3 3″ 483.3 1.0 5 11
KCB-633 4″ 633 0.28 5 11
KCB-960 4″ 960 0.3 5 18.5
KCB1200 6″ 1200 0.6 3 37
KCB1600 6″ 1600 0.6 3 45
KCB1800 8″ 1800 0.6 2.5 55
KCB2500 8″ 2500 0.6 2.5 75
KCB3800 10″ 3800 0.6 2 110
KCB5400 10″ 5400 0.6 2 110
KCB7600 14″ 7600 0.6 2 200
KCB9600 14″ 9600 0.6 2
