KCB 5400 gear pump for palm oil

  • item no.:

    KCB5400
  • lead time:

    Customer Date
  • product orgin:

    china saiken pumps
  • shipping port:

    Tianjin China
  • payment:

    L/C Or T/T
  • color:

    Customer Color
  • description
CE Approved KCB 5400 Palm Oil Gear Pump Specifications:


   Model        Capacity
        (L/min)
    Pressure
        (Bar)
    Speed
     (rpm)
     Caliber
      (inch)
    Power
     (kw)
        Efficiency
  KCB 5400          5400         6      989        10 "      110           44%
  Packing        details        1085*600*1155 for bare shaft pump   Export standard wooden case


Technical Data of KCB palm oil pump
MODEL: KCB-18.3,KCB-33.3,KCB-55,KCB-83.3,KCB-135,KCB-200,KCB-300,KCB-483.3,KCB-633, KCB-960,KCB-1200,KCB-1600,KCB-2500,KCB-3800,KCB-5400,KCB-9600.
Caliber:3/4 "-14 "
Capacity: 18.3-9600 lpm
Flow rate: 1.1 m3/h-570 m3/h
Rotational speed: 740 r/min-1440 r/min
Discharge pressure: 0.28 Mpa-1.45 Mpa
Suction head: 3-4 m
Motor power: 1.5KW-250KW.

KCB type gear oil pump used to delivery non-corrosive lubricating oil or similar liquid without Particle and fibers.If made of stainless steel, can be transferred palm oil, cooking oil, soybean oil, cooking oil,Modified Starch so on.

Temperature requirements: KCB type is not higher than 210 ℃, the viscosity of 5 x 10-6-1.5 x 10-3 m3 / s (5 to 1500 CST) lubricating oil or other liquid properties similar to lubricating oil. Reduce the pump speed, the viscosity of the medium to 5 x 104 CST.

CE Approved KCB5400 Palm Oil Gear Pump Model Parameters:


Model Caliber
(Inch)
Flow
(L/min )
Pressure
(MPa )
Suction Lift
(m )
kcb gear pump
with Motor power
(KW )
KCB-18.3 3/4 18.3 1.45 5 1.5
KCB-33.3 3/4 33.3 1.45 5 2.2
KCB-55 1″ 55 0.33 5 1.5
KCB-83.3 1 1/2″ 83.3 0.33 5 2.2
KCB-135 2″ 135 0.33 5 4
KCB-200 2″ 200 0.33 5 4
KCB-300 3″ 300 0.33 5 5.5
KCB483.3 3″ 483.3 0.33 5 7.5
KCB483.3 3″ 483.3 1.0 5 11
KCB-633 4″ 633 0.28 5 11
KCB-960 4″ 960 0.3 5 18.5
KCB1200 6″ 1200 0.6 3 37
KCB1600 6″ 1600 0.6 3 45
KCB1800 8″ 1800 0.6 2.5 55
KCB2500 8″ 2500 0.6 2.5 75
KCB3800 10″ 3800 0.6 2 110
KCB5400 10″ 5400 0.6 2 110
KCB7600 14″ 7600 0.6 2 200
KCB9600 14″ 9600 0.6 2 250
