32mm Air Operated Aodd Pump

Aodd Pumps Made of Cast steel,Aluminum,PP (polypropylene), Stainless steel (SS304, SS 316, SS 316L), PVDF,Teflon.

AODD pumps also called air operated diaphragm pumps, are positive displacement pumps driven and powered by compressed air rather than an electric motor. The AODD pump design means that it can cope with pretty much any fluid from water to viscous slurries to 90% solids including large, shear sensitive particles without degrading them. Air operated double diaphragm pumps are able to benefit from variable flow or pressures just by adjusting the air power supply.

32mm Aodd Pump Air Operated  Specifications:

Model SK-32
Max.Flow                                       40gpm (151Lpm)
Max.Working Pressure                     120psi(0.84Mpa, 8.4bar)
Fluid Inlet Size                                1-1/4inch / 32mm
Fluid Outlet Size                              1-1/4inch / 32mm
Air Inlet Size                                   1/2 inch.bsp(f)
Max.Suction Height(dry suction)        18ft. (5.48m)
Max.Permitted Grain                         1/8 inch (3.2mm)
Max.Air Consumption                        23.66 scfm
Every Reciprocating Flow                   0.15 gal (0.57L)
Max.Reciprocating Speed                   276 cpm
