Stainless Steel Rotary Gear Pumps for Shampoo

  • item no.:

    KCB18.3/55/83.3/200/300/483.3/633/960/1600/5400
  • lead time:

    Customer Date
  • product orgin:

    Made in china
  • shipping port:

    Tianjin China
  • payment:

    L/C Or T/T
  • color:

    Customer Color
  • description
We Saiken Pumps Manufacturer & dealer of Stainless steel gear pump in china offers high quality Stainless steel Gear Pump for high flow & pressure applications. Gear pumps are commonly used for loading & unloading of viscous liquid, transfer & filteration application.

Saiken Pumps offer SS Gear Pump suitable for pumping of viscous corrosive liquids like Acids, Solvents, Mineral Oils etc. SS gear pumps are modified by us for application in food industry by providing quick opening, fasteners for easy dismantling & assembly of the pump. So that it can be easily cleaned. Also, special food grade sealings provided to avoid contaminating of the food material. Our SS gear pumps are widely used in Chocolate, Butter, tomato sauce, fruit pulp, corn syrup pumping. Also, SS are widely used in pharmaceutical industries for transfer of medical syrups.

Saiken Pumps give a scope of excellent Stainless Steel Gear Pumps in china, which are broadly utilized for water driven liquid power applications in different ventures. Our Manufacturer & dealer of Stainless steel gear pump in china are appropriate for taking care of thick or semi visous fluids.These Stainless Steel gear pumps are fabricated using premium quality material which is procured from the reliable vendors of the market. Perfectly designed, these compact gear pumps are high in performance and deliver output with maximum accuracy. Our offered Stainless Steel pump are available in various specifications and are tested on a series of quality parameters to ensure their perfection in all aspects. Moreover, our clients can avail these SS gear pump manufacturer in china from us at market leading prices.

Pump available from size 3/4" to 14".
Pumps available in SS304, SS316
Capacity: 10 lpm to 9600 lpm
Sealing : Gland Packing/ Mechanical Seal
Pump Provided with inbuild relief valve
Useful for low to high viscocity liquid transfer
High Temperature: can be used for pumping hot liquid upto 220 C
Highly Recommended for viscous corrosive liquids pumping applications
Suitable for food and pharma industries

Model Capacity Q Speed
r/min
Exhaust
Pressure
Mpa
(NPSH)r
m
Efficiency
η %
Motor
m3/h L/min Power
kw
Model
KCB-18.3 1.1 18.3 1400 1.45 5 44 1.5 Y90L-4
2CY-1.1/1.45
KCB-33.3 2 33.3 1420 1.45 5 44 2.2 Y100L1-4
2CY-2/1.45
KCB-55 3.3 55 1400 0.33 7 41 1.5 Y90L-4
2CY-3.3/0.33
KCB-83.3 5 83.3 1420 0.33 7 43 2.2 Y100L1-4
2CY-5/0.33
KCB-135 8 135 940 0.33 5 46 2.2 Y112M-6
2CY-8/0.33
KCB-200 12 200 1440 0.33 5 46 4 Y112M-4
2CY-12/0.33
KCB-300 18 300 960 0.36 5 42 5.5 Y132M2-6
2CY-18/0.36
KCB-483.3 29 483.3 1440 0.36 5.5 42 11 Y160M-4
2CY-29/0.36
KCB-633 38 633 970 0.28 6 43 11 Y160L-6
2CY-38/0.28
KCB-960 58 960 1470 0.28 6.5 43 18.5 Y180M-4
2CY-58/0.28
KCB-1200 72 1200 740 0.6 7 43 37 Y280S-8
KCB-1600 95 1600 980 45 Y280S-6
KCB-1800 112 1800 740 0.6 7.5 43 55 Y315S-8
KCB-2500 150 2500 985 75 Y315S-6
KCB-2850 170 2850 740 0.6 8 44 90 Y315L1-8
KCB-3800 230 3800 989 110 Y315L1-6
KCB-4100 245 4100 743 0.6 8 44 132 Y355M1-8
KCB-5400 325 5400 989 160 Y355M1-6
KCB-5600 330 5600 744 0.6 8 44 160 Y355M2-8
KCB-7600 460 7600 989 200 Y355M3-6
KCB-7000 420 7000 744 0.6 8 44 185 Y355L1-8
KCB-9600 570 9600 989 250 Y355L2-6



tags :
